UNITEK-9400 Electro Mechanical Universal Testing Machine

UNITEK-9400 Electro Mechanical Universal Testing Machine Specification

Sensor
Not Available

Application
Industrial Labs

Speed Range
Adjustable

Power
220 Volt (v)

Screw Size
Customized

UNITEK-9400 Electro Mechanical Universal Testing Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
7 - 10 Days

Main Domestic Market
All India

About UNITEK-9400 Electro Mechanical Universal Testing Machine

The UNITEK-9400 Electro Mechanical Universal Testing Machine is designed for industrial labs, with a customized screw size for versatile testing applications. This machine operates on 220 Volt power supply and offers an adjustable speed range, making it suitable for a wide range of testing requirements. Equipped for precision and reliability, this universal testing machine ensures accurate results for various testing procedures.

Features :

Precision AC servo motor & drive with ball lead screw gives an advanced drive system with 1 to 1000 standard speed range.
Provision for load cell interchangeability & thereby automatic selection of load full scale & Units (kN or N)
Speed selection through data entry or variable speed through potentiometer
Facility for mounting different load cells & clamping devices to suit different tests & materials such as thin wires, metal sheets, fiber glass, leathers, springs, card boards etc.
Built-in parallel interface to connect Dot matrix printer for data & curve print-out
Safery interlock for overload & limit switch sensing to ensure protection during test
Universal applications in R& D, Education, Quality control & Production for test like, Tensile, Compression, Bending etc
